Advanced oil-free automatic template sewing machine designed for high precision, durability, and industrial-scale garment manufacturing operations.
Payment Term: T/T, L/C
Port: Ningbo / Shanghai
| Model | JK8310C-160105 | JK8310C-180105 | JK8310C-200105 | JK8310C-250105 |
|---|---|---|---|---|
| Sewing Range (X×Y) | 1600×1050mm | 1800×1050mm | 2000×1050mm | 2500×1050mm |
| Tabletop Size | 2100×2193mm | |||
| Laser Cutting Range | 1140×770mm (150W) | |||
| X-Beam | 1800 / 2000 / 2300 / 2500mm | |||
| Auxiliary Plate | 800 / 1000 / 1200mm | |||
| Stitch Type | Single-needle 301 Lockstitch | |||
| Max Speed | 3600 rpm/min | |||
| Stitch Length | 0.5 – 12.7mm | |||
| Needle Type | DB×1 (#8 – #14) | |||
| Hook Type | Full-rotation 2-fold rotating hook | |||
| Intermediate Presser Foot | Lifting 20mm | Stroke Standard 4mm | |||
| Program Input | USB | |||
